Small Samarium Cobalt High Temperature Circular Disc Magnet

Small Samarium Cobalt High Temperature Circular Disc Magnet

Samarium Cobalt magnets, with their high magnetic energy product, high coercivity, excellent temperature stability, corrosion resistance, play a crucial role in many high-end applications.

  • Size :

    D10x5mm
  • Order(MOQ) :

    1000pcs
  • Lead Time :

    3-15days
  • Payment :

    Paypal/ TT/Credit Card

Small Samarium Cobalt High Temperature Circular Disc Magnet

Product Description



Small Samarium Cobalt High Temperature Circular Disc Magnet
Size: D10x5mm
Materials: SmCo
Grade: SmCo2:17
Magnetization Direction: Thickness
Tolerance: +/-0.05mm
Working temperature: Maximum 300 Degree Celsius


Warning:

Keep away from pacemakers and children

If damaged please dispose of completely

Specification

Series Grade Br Hcb Hcj BHmax Tc
TW
T kGs kA/m kOe kA/m kOe kJ/m3 MGOe
SmCo 1:5 66800 SG 127/119 0.8 8 557 7 1194 15 127-143 16-18 750 250
66801 SG 143/119 0.85 8.5 621 7.8 1194 15 143-159 18-20
66802 SG 143/160 0.85 8.5 621 7.8 1592 20 143-159 18-20
66803 SG 160/119 0.9 9 637 8 1194 15 159-175 20-22
66804 SG 160/160 0.9 9 637 8 1592 20 159-175 20-22
66805 SG 175/119 0.95 9.5 676 8.5 1194 15 175-191 22-24
SmCo 2:17 60811 SG160/200 0.9 9 637 8 1990 25 159±16 20±2 800 350
60812 SG 175/160 0.95 9.5 653 8.2 1592 20 175±16 22±2 300
60813 SG 175/200 0.95 9.5 653 8.2 1990 25 175±16 22±2 350
60814 SG 191/160 1 10 676 8.5 1592 20 191±16 24±2 300
60815 SG 191/200 1 10 676 8.5 1990 25 191±16 24±2 350
60816 SG 207/160 1.02 10.2 716 9 1592 20 207±16 26±2 300
60817 SG 207/200 1.02 10.2 716 9 1990 25 207±16 26±2 350
60818 SG 223/120 1.06 10.6 763 9.6 1194 15 223±16 28±2 300
60819 SG 238/72 1.1 11 560 7 716 9 238±16 30±2 250



round samarium cobalt rare earth magnets



Strong samarium Cobalt magnets are a type of rare-earth permanent magnet composed primarily of samarium (Sm) and cobalt (Co). They are known for their excellent magnetic properties and stability.



High Magnetic Energy Product: Excellent magnetic performance, suitable for applications requiring strong magnetic fields.



High Coercivity: Strong resistance to demagnetization, making them ideal for high-temperature and high magnetic field environments.



Temperature Stability: Stable performance at high temperatures, with operational temperatures ranging from 250-350°c.



Corrosion Resistance: Good oxidation and corrosion resistance, typically requiring no additional coating.



Wide Range of Applications: Due to their excellent performance, custom SmCo magnets are widely used in various high-end fields.below is an introduction to the key applications of SmCo magnets:

1.Aircraft engines, satellite systems, and space exploration equipment.

2.Radar systems, missile guidance systems, and communication equipment.

3.Electric vehicle motors, wind turbine generators, and precision industrial motors.

4.Sensors, actuators, speakers, and hard disk drives.

5.Smartphones, laptops, and audio equipment.
