| Quantity: | |
|---|---|
| Items | Neodymium magnet raw material | |
| Material | neodymium-iron-boron | |
| Shape available | Disc,Cylinder,Block,Ring,Countersunk,Segment,Trapezoid, Irregular shapes and more; More shapes can be customized. | |
| Coating | Ni-Cu-Ni,Nickel,Zinc,Gold,Silver,Epoxy and more. | |
| Working Temperature | Grade | Temp.Coefficient |
| N35-N52 | 80°C (176°F) | |
| N35M-N45M | 100°C (212°F) | |
| N33H-N42H | 120°C (248°F) | |
| N30SH-N40SH | 150°C (302°F) | |
| N28UH-N35UH | 180°C (356°F) | |
| N28EH-N38EH | 180°C (356°F) | |
| N30AH-N33AH | 220°C (428°F) | |
| Technology | We have advanced R&D center,quality control and professional machining technicians. | |
| Application | Neodymium magnet raw magnetrials are widely used in industrial field,such as speaker, louder speaker,sensor,motor,alternator ect;And also it is popular in ladies bags,purses,shoes,crafts and jewelry ect. | |
| Grades | Remanence | Coercive Force | Intrinsic Coercivity | Maximum Energy product | Curie Temp | Temp Coefficient | ||||
| Br | Hcb | Hcj | (BH)max | TC | TW | |||||
| T | KGs | KA/m | Koe | KA/m | Koe | KJ/m3 | MGOe | ℃ | ℃ | |
| N35 | 1.18-1.23 | 11.8-12.3 | ≥ 868 | ≥ 10.8 | ≥ 955 | ≥12 | 263-287 | 33-36 | 310 | ≤80 |
| N42 | 1.28-1.34 | 12.8-13.4 | ≥ 923 | ≥ 11.6 | ≥ 1114 | ≥ 14 | 318-342 | 40-43 | 320 | |
