High-level 20*20*3mm Sintered Neodymium Magnet

Share to:
  • N40-N52,30M-50M,30H-48H,28SH-45SH,28UH-42UH,28EH-38EH,28AH-33AH
  • N40-N52,30M-50M,30H-48H,28SH-45SH,28UH-42UH,28EH-38EH,28AH-33AH
  • Super
  • 150 longton/month
  • Anhui,China
  • Standard Export Carton
  • piece 20*20*3mm Sintered Neodymium Magnet
  • 150 longton/month
  • 1, 20*20*3mm Sintered Neodymium Magnet
  • 5 days after deposit
  • 1
  • T/T

High-level 20*20*3mm Sintered Neodymium Magnet

Product name     20*20*3mm Sintered Neodymium Magnet
Material Neodymium iron boron
Grade & working Temperature Grade Max. Operating
Temperatures
N35-N45 80°C     (176°F)
N48-N52 60°C     (160°F)
35M- 50M 100°C   (212°F)
33H-48H 120°C   (248°F)
33SH-45SH 150°C   (302°F)
30UH-40UH 180°C   (356°F)
28EH-38EH 200°C   (392°F)
28AH-33AH 220°C   (428°F)
Shape Block
Coating Ni, Ni-Cu-Ni, Zn, Ag, epoxy, passivated,etc.
Certificate ISO9001, RoHS, REACH, Halogen testing pass.
Packing Standard sea or air packing, such as carton, iron, wooden box, etc.
Delivery date 5-12 days
Application Servo motor, brushless motor, texture motor, vibration motor, enerator, pump,
 special
motor, wind energy, lifter, speaker, magnetics switch, flow mere, CD-ROM, watt-hour meter,NMR, medical devices , separator, sensor, neodymium hard disk drive
 magnets

 applies in computers etc.

High-level 20*20*3mm Sintered Neodymium Magnet

Coating Characteristics
Plating Type Overall Thickness Salt Spray Test Pressure Cooker Test
NiCuNi(NickelCopper Nickel) 15-21 μm 24 hours 48 hours
NiCu + Black Nickel 15-21 μm 24 hours 48 hours
NiCuNi + Epoxy 20-28 μm 48 hours 72 hours
NiCuNi + Gold 16-23 μm 36 hours 72 hours
NiCuNi + Silver 16-23 μm 24 hours 48 hours
Zinc 7-15 μm 12 hours 24 hours
